MSI MPG B550 GAMING PLUS

Photos - Motherboard MSI MPG B550 GAMING PLUS
Videos 12Photos 6
MSI MPG B550 GAMING PLUS
Towards:gaming
Form Factor:ATX
Socket:AMD AM4
Chipset:AMD B550
BIOS:Ami
RAM slots:DDR4 4 sl
RAM form factor:DIMM
RAM clock:4400 MHz
Sound (channels):7.1
Connectors:HDMI, M.2
Additional connectors:DisplayPort
Power connector:24 pin
Processor power:8 pin

A well-equipped full-size ATX form factor gaming motherboard for AMD Ryzen processors based on the 2020 mid-range AMD B550 chipset. It is a balanced model from the MSI Performance Gaming overclocker family. Positioned as a product of the middle price category, designed to create overclocking and gaming configurations at a reasonable cost. Equipped with a powerful 12-phase Digital PWM processor power supply system, the power elements of which are cooled by impressive radiators.

It differs from previous generation boards based on B450 chipsets by supporting the high-speed PCI-E Gen 4.0 system interface, which makes it possible to double the speed of data exchange with high-speed NVMe SSDs and significantly speed up the loading of highly detailed textures in new graphics card models. MSI MPG B550 GAMING PLUS motherboard is fully compatible with Ryzen 3000 family CPUs (Matisse and Matisse Refresh cores, 7nm), Ryzen 4000 hybrid APUs (Renoir core, 7nm) and Ryzen 5000 processors (Vermeer core, 7nm). Supports work with high-speed DDR4 memory up to 128 GB (4x64 GB), which is enough for any current and future games. Equipped with two M.2 connectors for high-speed NVMe SSDs.

All specifications
Specifications MPG B550 GAMING PLUS
Main
Featuresgaming for overclocking
SocketAMD AM4
Form factorATX
Power phases12
VRM heatsink
LED lighting
Lighting syncMSI Mystic Light Sync
Size (HxW)305x244 mm
Chipset
ChipsetAMD B550
BIOSAmi
UEFI BIOS
RAM
DDR44 slot(s)
Memory moduleDIMM
Operation mode2 channel
Max. clock frequency4400 MHz
Max. memory128 GB
XMP
Drive interface
SATA 3 (6Gbps)6
M.2 connector2
M.21xSATA/PCI-E 4x, 1xPCI-E 4x
M.2 SSD cooling
Integrated RAID controller / RAID 0, RAID 1 and RAID 10 /
Expansion slots
1x PCI-E slots2
PCI-E 16x slots2
PCI Modes16x/4x
PCI Express4.0
CrossFire (AMD)
Steel PCI-E connectors
Internal connections
TPM connector
USB 2.02
USB 3.2 gen11
USB C 3.2 gen11
Video outputs
HDMI output
HDMI versionv.2.1
DisplayPort
Integrated audio
AudiochipRealtek ALC892 / ALC897 /
Sound (channels)7.1
Optical S/P-DIF
Network interfaces
LAN (RJ-45)1 Gbps
LAN ports1
LAN controllerRealtek 8111H
External connections
USB 2.04
USB 3.2 gen12
USB 3.2 gen21
USB C 3.2 gen21
PS/21
BIOS FlashBack
Power connectors
Main power socket24 pin
CPU power8 pin
Fan power connectors8
CPU Fan 4-pin1
CPU/Water Pump Fan 4-pin1
Chassis/Water Pump Fan 4-pin6
Official Websitemsi.com
Added to E-CatalogOctober 2020
The information in the model description is for reference purposes.
Always clarify the specifications and configuration of the product with the online store manager before purchasing.
