ASRock B850 Steel Legend WiFi AMD B850 Socket AM5 ATX B850 STEEL LEGEND WIFICLR


Steel Legend represents the philosophical state of rock-solid durability and irresistible aesthetics. Built around most demanding specs and features the Steel Legend series aims at daily users and mainstream enthusiasts! Providing a strong array of materials/components to ensure a stable and reliable performance.

- Supports AMD Socket AM5 Ryzen™ 9000 8000 and 7000 Series Processors
- 14+2+1 Phase Power Design 80A Dr.MOS for VCore+SOC
- 4 x DDR5 DIMMs
- Supports Dual Channel up to 8000+ (OC)
- 1 PCIe 5.0 x16 1 PCIe 4.0 x16
- Graphics Output Options: 1 HDMI
- Realtek ALC4082 7.1 CH HD Audio Codec Nahimic Audio
- 1 Blazing M.2 (PCIe Gen5x4)
- 3 Hyper M.2 (PCIe Gen4x4)
- 4 SATA3
- 1 USB 3.2 Gen2x2 Type-C (Front)
- 4 USB 3.2 Gen2 (2 Rear 2 Rear Type-C)
- 7 USB 3.2 Gen1 (3 Rear 4 Front)
- 8 USB 2.0 (4 Rear 4 Front)
- Realtek 2.5G LAN
- 802.11be Wi-Fi 7 + Bluetooth
- Supports Lite Release Design
- Toolless Multi-Layer M.2 Heatsink
- M.2 Bottom Heatsink



  Performance
- Exclusive 20K Cap with 1000uF Capacitance - The upgraded 20K Black capacitor not only extends the lifespan to 20000 hours but also increases the capacitance value from 560uF to 1000uF
- 14+2+1 Power Phase Design - Featuring sturdy components and completely smooth power delivery to the CPU. Plus it offers unmatched overclocking capabilities and enhanced performance with the lowest temperature for advanced gamers as well.
- Dr. MOS - Dr.MOS is the integrated power stage solution which is optimized for synchronous buck-set down voltage applications! Compared to traditional discrete MOSFETs it intelligently delivers higher current for each phase thus providing improved thermal result and superior performance.
- Hi-Density Power Connector - CPU overclocking requires higher current. ASRock Hi-Density Power Connectors are designed to withstand higher currents compared to traditional CPU and ATX power connectors providing a more stable system and reducing the risk of fire during heavy overclocking.
- 8 Layer PCB - The 8 Layer PCB provides stable signal traces and power shapes delivering lower temperature and higher energy efficiency ensures a reliable and long-lasting system while delivering ultimate performance without any compromise.
- DDR5 XMP & EXPO Support - Derived from the “built for stable and reliable” designing concept ASRock does not compromise on any details. This motherboard is built with high quality materials enthusiasts are able to enjoy the boost of DDR5 memory overclocking performance by enabling the pre-tested profiles. Make sure the memory modules are Intel® XMP/AMD EXPO™ capable and overclocking can be made so affordable satisfying and absolutely no sweat at all.




  High Speed M.2
