The advanced Midi Tower gaming case features a reverse motherboard mounting technology that allows hiding all cables from the front side. This feature creates an exceptionally clean and aesthetic appearance within the glass "aquarium," showcasing components without the visual noise of wires. Dimensions of 415x288x438 mm provide spacious interior space for graphics cards up to 420 mm and large power supplies up to 220 mm, catering to the needs of the most demanding configurations.

The Jonsbo TK-3 case comes without pre-installed fans, giving enthusiasts complete freedom to create a personalized cooling system based on aesthetic and acoustic preferences. Ten mounting positions offer exceptional flexibility, including three side positions for additional component airflow. The reinforced steel construction with 0.7 mm wall thickness and a weight of 7.3 kg ensures reliability and minimization of vibrations. Support for large liquid cooling systems up to 360 mm at the top and bottom opens opportunities for extreme thermal management. The front panel is equipped with high-speed USB-C 3.2 gen2 and two USB 3.2 gen1 ports. Dust filters protect components, while rubberized feet provide stability.

All specifications

Specifications TK-3 Black

Colour

Features	gaming
Form factor	Midi Tower
Mount	vertical
Motherboard support	ATX
Board placement	vertical
Reverse layout motherboard support
Dual chamber body
PSU form factor	ATX (regular)


Computer case
Dimensions (HxWxD)	415x288x438 mm
PSU max lenght	220 mm
Graphics card max lenght	420 mm
Fan max height	165 mm
Weight	7.3 kg
Material	steel
Sidewall thickness	0.7 mm
Rubber feet
Side panel	removable


Storage
PSU
PSU mount	bottom
3.5" bays	1
internal 2.5" compartments	2
Expansion slots	7

Cooling
Fans (back)	1x120mm
Fans (side)	3x120mm
Fans (top)	2x140mm / 3x120mm /
Fans (bottom)	3x120mm
Fan mounts total	10
Dust filter	top and bottom
Liquid cooling support


Liquid cooling system
Liquid cooling (top)	360mm
Liquid cooling (bottom)	360mm
Liquid cooling mounts	2


Connectors and functions
Placement	on the front
USB A 5Gbps (3.2 gen1)	2 pcs
USB C 10Gbps (3.2 gen2)	1 pcs
Audio (microphone/headphones)


More features
Front panel	glass
Side panel window	tempered glass
More features	hidden wiring CPU cooling mount window
Official Website	jonsbo.com
Added to E-Catalog	July 2024

The information in the model description is for reference purposes.
Always clarify the specifications and configuration of the product with the online store manager before purchasing.
Catalog Jonsbo 2026 - new arrivals, bestsellers, and the most relevant models Jonsbo.

How to choose a PC case?Basic factors for choosing a stylish computer case with good functionality and efficiency

Shine Bright: Everything You Ever Wanted to Know About PC RGB LightingWe understand how the backlight appeared in the PC, how it is useful, and what synchronization systems are on the market

User reviews ₁

Write Review →

There are better options

3 December 2025

Terrible case. Starting from the power button, ending with poor materials and engineering prob*ems. Some water coolers like the Arctic Freezer 3 360 cannot fit with the massive top radiators on the motherboard. The back panel is made as a monolith, this is the level of cases under €2,000.

slope

Rear stick, power button, no mesh.
