ATEN VE811R AV receiver Black VE811R-AT-E
 |
Buy ATEN VE811R AV receiver Black VE811R-AT-E
When you make a purchase through links on our site, we may receive a affiliate commission.
HDMI HDBaseT Receiver VE811R-AT-G | £145.75 |  | |||
ATEN VE811R AV receiver Black VE811R-AT-E | £235.51 |  | |||
Aten VE811R-AT-E
Product Key Features
• HDBaseT Connectivity – extends an HDMI connection up to 100m via a single Cat 5e/6/6a or ATEN 2L-2910 Cat 6 cable.
• HDMI (3D Deep Color 4K).
• HDCP 2.2 compatible.
Product Overview
The ATEN VE811R HDMI HDBaseT Receiver guarantees the optimum HDMI connection up to 100 m over a single Cat 5e/6/6a or ATEN 2L-2910 Cat 6 cable. The VE811R meets HDMI Specification features including 3D Deep Color HD lossless audio formats and CEC pass through. It supports Dolby Digital 5.1 DTS HD audio and video signals at resolutions up to 4K.
Pushing the technology and design to the limit the compact design makes the VE811R easy to mount in any location. Engineered for today’s digital trends the VE811R is ideal for meeting rooms or any setting that requires high quality HDMI video to be extended for great distances.
Product Package Contents
• 1x VE811R HDMI HDBaseT Receiver.
• 1x Power Adapter.
• 1x User Instructions.
More Product Key Features
• HDBaseT Connectivity – extends an HDMI connection up to 100m via a single Cat 5e/6/6a or ATEN 2L-2910 Cat 6 cable.
• HDMI (3D Deep Color 4K).
• HDCP 2.2 compatible.
• Supports resolutions of up to Ultra HD 4kx2k and 1080p Full HD.
• Supports wide screen format.
• Plug and play – no software required.
• Built- in 8KV/ 15 KV ESD protection.
• Rack Mountable.
Product Specifications
Video Output
• Interfaces: 1 x HDMI Type A Female (Black).
• Impedance: 100 ??.
• Max. Distance: 3 m (2L-7D03H).
Video
• Max. Data Rate: 10.2Gbps (3.4Gbps per lane).
• Max. Pixel Clock: 340 MHz.
• Compliance: HDMI (3D Deep Color 4K) HDCP2.2 Compatible Consumer Electronics Control (CEC)
• Max. Resolutions / Distance: Up to 4K@70m (Cat 5e/6) / 100m (Cat 6a/ATEN 2L-2910 Cat6); 1080p@ 100m (Cat 5e/6/6a)
*4K supported: 4096 x 2160 / 3840 x 2160 @ 60Hz (4:2:0); 4096 x 2160 / 3840 x 2160 @ 30Hz (4:4:4).
Audio
• Output: 1 x HDMI Type A Female (Black).
Connectors
• Unit To Unit: 1 x RJ-45 Female.
• Firmware Upgrade: 1 x Mini Stereo Jack Female (Black).
• Power: 1 x DC Jack (Black) with locking.
Switches
• Long Reach Mode Switch: 1 x Slide Switch - ON/OFF
Power Consumption
• DC5V:3.84W:18BTU.
Environmental
• Operating Temperature: 0 - 40?C.
• Storage Temperature: -20 - 60?C.
• Humidity: 0 - 80% RH Non-Condensing.
Physical Properties
• Housing: Metal.
• Weight: 0.17 kg ( 0.37 lb ).
• Dimensions (L x W x H) with bracket: 8.64 x 7.30 x 2.47 cm (3.4 x 2.87 x 0.97 in.).
• Dimensions (L x W x H) without bracket: 8.20 x 5.20 x 2.37 cm (3.23 x 2.05 x 0.93 in.).
