Tecware black (TW-CA-NEXUS-M-BK)
 | Outdated Product A compact and relatively inexpensive gaming platform, the capabilities of which go far beyond its value category. So, the model belongs to the Mini Tower form factor, has a laconic design and an extremely efficient cooling system. The motherboard tray is ready to accommodate any of the modern MicroATX or Mini-ITX solutions. The compact form factor does not interfere with the system to use high-performance graphics and a powerful processor — 340 mm is allocated for video, and a tower up to 155 mm high can be installed to cool the CPU. Despite the affordable cost of the case, Tecware Nexus M received a magnetic dust grid both in front and on top. For fresh air intake, two pre-installed 120 mm fans are used. The front ventilation ducts are located on the side and bottom, another 120 mm fan th...at blows out is installed on the rear panel. There is also a large ventilation duct on the top cover, it is represented by extensive perforation. The power supply has space in the lower compartment. Of the memory drives, you can use two HDD 3.5 ″ devices and the same number of SSD 2.5 ″. There are four plugs for installing PCI expansion cards. The interface panel is located at the front edge of the top cover, it has: USB ports (one 3.0 and two 2.0), mini-Jack connectors, power and reset buttons. |
 |
Close
We recommend products in stockComputer Cases Tecware →
Tecware black
Chassis Form Factor:Mini Tower
Motherboard size:micro-ATX
PSU power:no PSU
Internal bays 3.5":2
Internal bays 2.5":2
Front panel:USB A 3
A compact and relatively inexpensive gaming platform, the capabilities of which go far beyond its value category. So, the model belongs to the Mini Tower form factor, has a laconic design and an extremely efficient cooling system. The motherboard tray is ready to accommodate any of the modern MicroATX or Mini-ITX solutions. The compact form factor does not interfere with the system to use high-performance graphics and a powerful processor — 340 mm is allocated for video, and a tower up to 155 mm high can be installed to cool the CPU.
Despite the affordable cost of the case, Tecware Nexus M received a magnetic dust grid both in front and on top. For fresh air intake, two pre-installed 120 mm fans are used. The front ventilation ducts are located on the side and bottom, another 120 mm fan that blows out is installed on the rear panel. There is also a large ventilation duct on the top cover, it is represented by extensive perforation. The power supply has space in the lower compartment. Of the memory drives, you can use two HDD 3.5 ″ devices and the same number of SSD 2.5 ″. There are four plugs for installing PCI expansion cards. The interface panel is located at the front edge of the top cover, it has: USB ports (one 3.0 and two 2.0), mini-Jack connectors, power and reset buttons.
All specifications
Specifications Nexus M Black
|
| ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
The information in the model description is for reference purposes.
Always clarify the specifications and configuration of the product with the online store manager before purchasing.
Catalog Tecware 2025 - new arrivals, bestsellers, and the most relevant models Tecware.
Always clarify the specifications and configuration of the product with the online store manager before purchasing.
Catalog Tecware 2025 - new arrivals, bestsellers, and the most relevant models Tecware.
How to choose a PC case?Basic factors for choosing a stylish computer case with good functionality and efficiency
Shine Bright: Everything You Ever Wanted to Know About PC RGB LightingWe understand how the backlight appeared in the PC, how it is useful, and what synchronization systems are on the market
AccessoriesAll accessories for Tecware Nexus M Black →
I quite liked the case overall. I bought the Black/Red version, and the appearance really appealed to me; it's important to have red among the components as well, as it looks really cool together. The case itself is spacious inside despite its relatively compact size. A graphics card with three fans fit in without any problem. However, there's a catch - you cannot install a tall CPU cooler. The max height specified is 155mm, but it's actually around 160mm, so be mindful when selecting a cooler for the processor. In terms of the case assembly, I have no complaints; the quality of the materials is quite decent, the metal doesn't feel flimsy or creak. The glass is thick and arrived without any scratches, covered in film. There are also some less pleasant aspects. Cable management isn't very well thought out, with too little space between the panel and the rack, which made it a bit of a hassle to manage the wires properly. It was also concerning that air intake at the front is essentially only at the bottom, with no side vents. And minor things like the absence of rubber pads under the PSU, etc. However, considering the price, I think these are things you can overlook. Overall, I can recommend it, I'm satisfied. Beautiful, compact, modern case, dust filters, tempered glass. For this price, despite minor drawbacks, I consider it a successful purchase. Didn't like that the cable management is poorly designed, there's little space for laying out between the panels. If they had literally added just 10 mm more space, I would have given the highest rating.  Evgeniy: use Tecware Nexus M Black less than month |
Used this for a little over three years. The case is decent if you build a PC without a dedicated graphics card, using the processor's integrated graphics. Any discrete graphics card inside will struggle with cooling because the case is compact and air circulation is very poor. Although it's the only major drawback, it's significant. Otherwise, it's not bad for the price; the build quality is good, and the metal is decent, not like foil. It has dust filters. Included screws should be thrown away right away. Workmanship, the presence of dust filters. Looks more expensive than it is. Very poor ventilation, the iron inside literally suffocates, huge temperatures and noise. Mister Kon: use Tecware Nexus M Black more than year |
Add Review
Video reviews
BUILD LOG: Project White Lies | CEBU CITY | Tecware NEXUS M
29 May 201859 205 view
BUILD LOG: Hargie Tan | BACOLOD CITY | Tecware NEXUS M
10 June 201850 657 view
SEXY TEMPERED GLASS CASE FOR PHP 2,000 (US$40 Est.) - Tecware Nexus Unboxing & Review
6 July 201840 074 view
BUILD LOG: Juliet Lavilla | BACOLOD CITY | Tecware NEXUS M Tempered Glass
13 February 202025 963 view
TECWARE Nexus M2 Air (Quick Review) For None RGB Build
19 September 202125 803 view
BUILD LOG: Clint Maverick Wee | ZAMBOANGA CITY | Tecware NEXUS M
28 June 201813 974 view
BUILD LOG: Nykko Raven Fuentes Millanes | GETAFE, BOHOL | Tecware NEXUS M
18 September 20189 029 view
Client Build: Charles Jonelas | BACOLOD CITY | Tecware NEXUS M Tempered Glass
